HSK-3500 Multi-Profile Steel Framing Machine
Review the HSK-3500 as a CC/CU framing-machine candidate only after our factory team checks your approved sections, coil, holes and production schedule. A shared 3500/4000/4500 catalogue description is not a model-specific guarantee.
HSK-3500 / 4000 / 4500 catalogue rendering, with HSK-3500 shown on the housing. This is a production-base rendering, not a photograph of the machine currently offered. Ask for build-specific photos, a written configuration and measured trial parts.
When does the HSK-3500 merit a technical review?
Direct answer: Consider this member of the multi-profile family when the order requires more than one approved CC/CU framing section and the punching and changeover scope matters. Our Xiamen production base's public catalogue groups HSK-3500 with 4000 and 4500; group-wide features and ranges cannot be assigned to the 3500 variant without the current model-specific technical offer.
Start with a revision-controlled drawing for each required C and U member. Identify steel grade, thickness range, flange and lip details, hole datum and spacing, cut lengths and accepted output per shift. Then ask which of those sections and features the proposed HSK-3500 tool set covers. Compare alternatives using the same material and trial method.
The stud and track buyer page addresses partition-wall C-stud/U-track decisions. This page addresses the named HSK-3500 candidate and its model-specific evidence. If the production plan also includes truss or floor members, list them as separate drawings rather than assuming a machine-family label covers them.
What must be confirmed for the exact HSK-3500 build?
| Production-base family description | Evidence required for the quoted 3500 |
|---|---|
| CC and CU profile production | Approved section list, tooling envelope and identified samples at the required extremes |
| Automatic size or profile adjustment | Which axes change by recipe, which tools or guides need manual work, and both changeover directions |
| Multiple punching functions | Hole schedule on each drawing, included punch/die list and measured hole-to-datum results |
| Data import and part identification | Supported production-file format, revision control and whether marking is included |
| Nominal speed or output | Accepted pieces during the agreed material, punching, cutting and discharge trial |
Request a written inclusions/exclusions schedule for decoiler, guarding, cutting, run-out, data interface, commissioning and test material. A published group specification is a starting point for questions, not a substitute for the contract and factory acceptance record.
How to test the offered framing-machine configuration
- Record the approved revision, coil identity and material certificate for each trial section.
- Form a C and a U member at the smallest and largest required section settings where the quotation says they are covered.
- Run the buyer's hole layout; measure section dimensions, hole positions and cut length on labelled first-off and repeat parts.
- Record every operator step and rejected part during the C-to-U and U-to-C transitions.
- If truss features or special punching are in the contract, trial those drawings and tools separately before acceptance.
Keep a signed deviation list for anything the machine did not demonstrate. See the stud and track procurement checklist for the underlying drawing and sample record. No site photograph or catalogue headline alone proves a production rate or structural-system compliance.
What is verified about the model family?
our Xiamen production base's public multi-profile steel framing system page names HSK-3500 together with 4000 and 4500 and describes CC/CU production, profile changeover and punching functions. Reviewed 2 October 2026. Because that page groups models, this Halcyon buyer guide does not present its thickness, web-width, speed, precision, power or accessories as guaranteed HSK-3500 values. Our factory team must identify the exact machine and issue the current technical proposal and test criteria.
Halcyon Machinery handles equipment selection with our factory team at our Xiamen production base. Our Xiamen production base's HSK-3500 catalogue rendering above is for orientation only; request actual build photos and our written scope.
Send the sections to compare
Share the profile drawings, steel grade, thickness range, punching layout, target output and destination electrical requirements. We can then request a model-specific scope and acceptance plan from our factory team.
- C and U section drawings
- Steel grade and thickness range
- Hole datum and punching layout
- Cut lengths and output target
- Destination voltage and installation site
